ASTM Standard List - Structural and Constructional Steels Standards: Part Five
Abstract
ASTM specifications represent a consensus among producers, specifiers, fabricators, and users of steel mill products. ASTM’s designation system for metals consists of a letter (A for ferrous materials) followed by an arbitrary sequentially assigned number. These designations often apply to specific products, for example A548 is applicable to cold-heading quality carbon steel wire for tapping or sheet metal screws.
This article contains a list of standards that covers among other things:
- Bolts, bars and piping used specifically in the construction industry
- Steel wires for masonry joining applications
- Carbon steel sheets with ultra-high strengths
For more information on the ASTM designation system see our related article:
Introduction to the ASTM Standard Designation.
Structural and Constructional Steels: Part Five
| Standard Number |
Last version |
Description | Status |
| A 896 | 2009 | Standard Practice for Conducting Case Studies on Galvanized Structures | /no materials/ |
| A 905 | 2004 | Steel Wire, Pressure Vessel Winding | /2/ |
| A 906/A 906M | 2002 | Grade 80 and Grade 100 Alloy Steel Chain Slings for Overhead Lifting | /no materials/ |
| A 907/A 907M | 1996 | Steel, Sheet and Strip, Heavy Thickness Coils, Carbon, Hot-Rolled, Structural Quality | Replaced by A1018/A1018M /4/ |
| A 910/A 910M | 2005 | Uncoated, Weldless, 2- and 3-Wire Steel Strand for Prestressed Concrete | /2/ |
| A 911/A 911M | 2005 | Uncoated, Stress-Relieved Steel Bars for Prestressed Concrete Ties | /1/ |
| A 913/A 913M | 2007 | High-Strength Low-Alloy Steel Shapes of Structural Quality, Produced by Quenching and Self-Tempering Process (QST) | /4/ |
| A 914/A 914M | 2005 | Steel Bars Subject to Restricted End-Quench Hardenability Requirements | /23/ |
| A 920/A 920M | 2007 | Steel Bars, Microalloy, Hot-Wrought, Special Quality, Mechanical Properties | /36/ |
| A 921/A 921M | 2005 | Steel Bars, Microalloy, Hot-Wrought, Special Quality, for Subsequent Hot Forging | /6/ |
| A 936/A 936M | 1997 | Steel, Sheet and Strip, Heavy Thickness Coils, High Strength, Low-Alloy, Hot-Rolled, with Improved Formability | Replaced by A1018/A1018M /4/ |
| A 945/A 945M | 2006 | High-Strength Low-Alloy Structural Steel Plate with Low Carbon and Restricted Sulfur for Improved Weldability, Formability, and Toughness | /2/ |
| A 951/A 951M | 2006 | Steel Wire for Masonry Joint Reinforcement | /1/ |
| A 960/A 960M | 2008 | Common Requirements for Wrought Steel Piping Fittings | /no materials/ |
| A 961/A 961M | 2008 | Common Requirements for Steel Flanges, Forged Fittings, Valves, and Parts for Piping Applications | /no materials/ |
| A 962/A 962M | 2009 | Common Requirements for Steel Fasteners or Fastener Materials, or Both, Intended for Use at Any Temperature from Cryogenic to the Creep Range | /no materials/ |
| A 963/A 963M | 1997 | Deep Drawing Steel (DDS), Sheet, Carbon, Cold-Rolled | Replaced by A1008/A 1008M /no materials/ |
| A 964/A 964M | 2003 | Corrugated Steel Box Culverts | /no materials/ |
| A 969/A 969M | 1997 | Extra Deep Drawing Steel (EDDS), Sheet, Carbon, Cold-Rolled | Replaced by A1008/A 1008M /no materials/ |
| A 970/A 970M | 2009 | Headed Steel Bars for Concrete Reinforcement | /no materials/ |
| A 973/A 973M | 2007 | Grade 100 Alloy Steel Chain | /no materials/ |
| A 979/A 979M | 2009 | Concrete Pavements and Linings Installed in Corrugated Steel Structures in the Field | /no materials/ |
| A 980 | 2003 | Steel, Sheet, Carbon, Ultra High Strength Cold Rolled | /4/ |
| A 984/A 984M | 2009 | Steel Line Pipe, Black, Plain-End, Electric-Resistance-Welded | /8/ |
| A 992/A 992M | 2006 | Structural Steel Shapes | /1/ |
| A 994 | 2009 | Standard Guide for Editorial Procedures and Form of Product Specifications for Steel, Stainless Steel, and Related Alloys | /no materials/ |
| A 996/A 996M | 2009 | Rail-Steel and Axle-Steel Deformed Bars for Concrete Reinforcement | /6/ |
| A 1005/A 1005M | 2004 | Steel Line Pipe, Black, Plain End, Longitudinal and Helical Seam, Double Submerged-Arc Welded | /5/ |
| A 1006/A 1006M | 2004 | Steel Line Pipe, Black, Plain End, Laser Beam Welded | /5/ |
| A 1007 | 2007 | Carbon Steel Wire for Wire Rope | /no materials/ |
| A 1008/A 1008M | 2009 | Steel, Sheet, Cold-Rolled, Carbon, Structural, High-Strength Low-Alloy, High-Strength Low-Alloy with Improved Formability, Solution Hardened, and Bake Hardenable | /43/ |
| A 1014/A 1014M | 2009 | Precipitation-Hardening Bolting Material (UNS N07718) for High Temperature Service | /1/ |
| A 1017/A 1017M | 2007 | Pressure Vessel Plates, Alloy Steel, Chromium-Molybdenum-Tungsten | /3/ |
| A 1018/A 1018M | 2009 | Steel, Sheet and Strip, Heavy-Thickness Coils, Hot-Rolled, Carbon, Commercial, Drawing, Structural, High-Strength Low-Alloy, High-Strength Low-Alloy with Improved Formability, and Ultra-High Strength Steel | /55/ |
| A 1020/A 1020M | 2007 | Steel Tubes, Carbon and Carbon Manganese, Fusion Welded, for Boiler, Superheater, Heat Exchanger and Condenser Applications | /3/ |
| A 1030/A 1030M | 2005 | Standard Practice for Measuring Flatness Characteristics of Steel Sheet Products | /no materials/ |
| A 1031 | 2009 | Steel, Sheet and Strip, Heavy-Thickness Coils, Alloy, Drawing Steel and Structural Steel, Hot-Rolled | /49/ |
| A 1035/A 1035M | 2009 | Deformed and Plain, Low-carbon, Chromium, Steel Bars for Concrete Reinforcement | /2/ |
| A 1040 | 2009 | Standard Guide for Specifying Harmonized Standard Grade Compositions for Wrought Carbon, Low-Alloy, and Alloy Steels | /341/ |
| A 1041/A 1041M | 2009 | Pressure Vessel Plates, Alloy Steel, Higher Strength Chromium-Molybdenum-Tungsten | /2/ |
| A 1042/A 1042M | 2009 | Composite Corrugated Steel Pipe for Sewers and Drains | /no materials/ |
| A 1043/A 1043M | 2009 | Structural Steel with Low Yield to Tensile Ratio for Use in Buildings | /4/ |
| A 1044/A 1044M | 2005 | Steel Stud Assemblies for Shear Reinforcement of Concrete | /2/ |
| F 432 | 2008 | Roof and rock bolts and accessories | /5/ |
| F 436 | 2009 | Hardened steel washers | /2/ |
| F 541 | 2004 | Alloy steel eyebolts | /2/ |
| F 568M | 2007 | Carbon and alloy steel externally threaded metric fasteners | /19/ |
April, 2011
